Should that disc be epoxied to the diaphragm? I have carbs with both styles plus some with no disc. The best runner is with the large disc. Thanks!

I had the same thing happen, and used a fine wire and WD40 over a period of time to loosen the varnish in the tank line. Like mentioned before, the small screen is very delicate!

Is it possible to get a copy of those sales brochures?

It is part of a kill switch. Mine is broken too and I think I found one on the Bay for $20. I just choke it to stop.

Yup, I think you're correct on that. I didn't study all the photos, just the one from the side which looked simply like a strap had been fashioned to fasten the front handle. I noticed now that it even has the starting instruction decal applied on the top too. There seems to be a large number of variations for us to collect!

That looks like a homemade fix for the missing clutch cover. Fortunately, that's an easy part to find.

I had the same thing happen to a carb I was rebuilding. Flooded all the time until i filed the button down to the same height as the original. It's aluminum and won't take very long to fix it . Make sure the gasket is first on the carb base, then the metering diaphragm.

Outboard motors are water cooled and don't generate the higher temps that air cooled motors can. The oils are formulated differently for a reason. I use Amsoil Saber mixed with non-ethanol fuel at 32-1 on every air cooled 2 cycle engine I have. (100+) From the O & R's up to the big 118cc Sachs Dolmar saws.

Looks to me that they tried to make the old carb more modern and added a diaphragm fuel pump. I'd say that line coming out by the motor mount would be the pulse port for the pump, and the other line feeding fuel from the tank.

Flip the petal over. I've pulled on the starter cord too many times to no avail, on an engine with a broken or leaky reed valve. I'm a little smarter now!

I think the decal would not be noticeable, but in fact looks great. However, as a chainsaw enthusiast, I'd point out that the chain is on backwards in the pics. I'd really like to add one of those Mono saws to my collection. They look like a design that is much more practical and robust if one were to use it, and certainly much easier to work on than my Lancaster and Orline saws.

I'm thinking that I could almost hear the exhaust noise from that engine at my house! Neat project!

My first O & R chainsaw project had the same wire pinch with corresponding results. I used liquid tape and routed it properly.

Here is an enlarged picture of my tank.

This does indeed have the screw in handle, it's just not very visible in the first picture.
