The footrests were another item I had a few attempts at before finishing up with something that looked right in comparison with the rest of the build.  One pair looked too long and narrow, another try ended up with the fold overs not being deep enough.  Fairly quick to mark out and make so not too much hair pulled out.  Again, made from the scrap 1mm alloy panels. The first attempts found a use elsewhere after being cut up.



How to make the fenders. ?  Simply bending up on the brake press wasn't thought viable due to the curves at each end, although I now think it could have been done with a bit of NON press work included.    Also the corners would need alloy welding etc.  Another possibility was making a plug and moulding in fiber glass.   I decided to make these using built up layers of plasticard sheet reinforced with alloy.  I already had a good stock of this plasticard.   This resulted in very strong fenders.  The plastic, welded together with liquid polystyrene cement, was thick enough to sand the curves on ends and sides.  The alloy inserts were a very tight fit after making a few short trial sections to get the bends in the correct place.   Also bolted at the corners although they wouldn't come out easily.  The top of each footrest slides into the slot at the front of the fenders and will be bolted in place when finished.






went to South Lincolnshire last week to collect a Mayfield and came back with a lot more numerous boxes of spares, brand new Planet Junior hoe blades, ducks feet and a sprayer

Today's progress has been a bit slow due to a very stubborn hub, i warmed it up and bolted a puller on but no joy.
I gave it a good soaking and tried again still wouldn't move.
Next I connected up the gas axe to get more heat and quicker, with it glowing it still refused to move so i went for a cuppa to cool off.
I thought I'd give it one more chance if not I decided to leave it rather than brake it.
Same again with loads of heat and an extension pipe on my T bar it moved and off it came, next was the other side so with puller fitted it slid straight off.
It was a lot of work but at least i got them off and can change the oil seals and I didn't break anything.

I had to leave this for a few days as i had other commitments namely mot on the Sprinter and the Chevy .
Im sorting out the transmission that seems to be weeping oil and the hitch pin is rusted solid which will need drilling out.
I pulled another box out but thought I'd carry on with the original.
I had to leave it over night to let whatever was in it to dribble out, it certainly wasn't sae 140.
I cut through the pin each side to remove the hitch and spacers the cut it again near the casing, drilled a hole through the pin using 3 different sizes drill bits then nocked it out.
Ive ordered some new axle seals from Toro and think i have the others in stock.
Next job will be to remove all the pulleys and hubs and clean it up.
Heres some photos of today's activities.
